@jumentix/cana

IndexedDB offline database adapter for Jumentix applications.

import { createClient } from '@jumentix/cana';

const client = createClient({
  name: 'tasks-app',
  schema: {
    version: 1,
    stores: [
      { name: 'categories', keyPath: 'id', indexes: [{ name: 'byName', keyPath: 'name' }] },
      {
        name: 'tasks',
        keyPath: 'id',
        indexes: [
          { name: 'byCategory', keyPath: 'categoryId' },
          { name: 'byUpdatedAt', keyPath: 'updatedAt' }
        ]
      }
    ]
  }
});

await client.open();
await client.table('categories').put({ id: 'work', name: 'Work' });
await client.table('tasks').add({
  id: 'task-1',
  title: 'Write the Cana tutorial',
  categoryId: 'work',
  completed: false,
  updatedAt: Date.now()
});

Responsibility in context

• Stack layer: offline / browser persistence adapter
• Owns: IndexedDB client API for PWAs
• Used with: @jumentix/cana-react, @jumentix/cana-vue, designer-core, SPA/PWA guide, service-management
• Not responsible for: server databases, Redis KV, REST/WebSocket protocols

Three things to know before using it

IndexedDB is the durable browser database. Cana keeps the public API close to IndexedDB semantics: explicit open(), stable schema versions, indexed tables, atomic transactions and committed change events. If you need storage diagnostics, use storageState() and durabilityAssessment() after the client opens.

Writes have three outcomes, not two. committed | rolled-back | unknown. The third covers a transaction torn down without either event firing — a killed worker, a closed tab. Enable operationLedger: true and resolveWrite() will answer definitively, because the operation id is written inside the same transaction as the data.

Never await anything but an IndexedDB request inside a transaction. The transaction auto-commits as soon as the event loop yields with no pending request, so await fetch(...) does not pause it — it ends it. Cana reports the violation as TransactionInactive rather than letting a bare DOMException escape.

Errors are plain data

CanaError is not an Error subclass, because structured clone does not preserve class identity across storage or a worker boundary — an instanceof check would silently return false. Use the guards:

import { isCanaError, isCanaErrorCode } from '@jumentix/cana';

try {
  await client.table('tasks').add({
    id: 'task-1',
    title: 'Write the Cana tutorial',
    categoryId: 'work',
    completed: false,
    priority: 'high',
    createdAt: Date.now(),
    updatedAt: Date.now()
  });
} catch (error) {
  if (isCanaErrorCode(error, 'QuotaExceeded')) {
    console.warn('Storage quota is full. Export or clear local data before retrying.');
  } else if (isCanaError(error)) {
    console.warn(`Cana failed with ${error.code}: ${error.message}`);
  } else {
    throw error;
  }
}

Try it in the browser

Run a first client against IndexedDB in this page:

### Getting started

```ts
const client = cana.createClient({
  name: dbName,
  schema: {
  version: 1,
  stores: [
    { name: 'categories', keyPath: 'id', indexes: [{ name: 'byName', keyPath: 'name', unique: true }] },
    {
      name: 'tasks',
      keyPath: 'id',
      indexes: [
        { name: 'byCategory', keyPath: 'categoryId' },
        { name: 'byCompleted', keyPath: 'completed' },
        { name: 'byUpdatedAt', keyPath: 'updatedAt' }
      ]
    }
  ]
}
});
await client.open();
await client.table('categories').add({
  id: 'work',
  name: 'Work',
  color: '#2563eb',
  createdAt: Date.now(),
  updatedAt: Date.now()
});
await client.table('tasks').add({
  id: 'task-1',
  title: 'Write the Cana tutorial',
  categoryId: 'work',
  completed: false,
  priority: 'high',
  createdAt: Date.now(),
  updatedAt: Date.now()
});
return {
  backend: client.backend,
  category: await client.table('categories').get('work'),
  task: await client.table('tasks').get('task-1')
};
```

const client = cana.createClient({
  name: dbName,
  schema: {
  version: 1,
  stores: [
    { name: 'categories', keyPath: 'id', indexes: [{ name: 'byName', keyPath: 'name', unique: true }] },
    {
      name: 'tasks',
      keyPath: 'id',
      indexes: [
        { name: 'byCategory', keyPath: 'categoryId' },
        { name: 'byCompleted', keyPath: 'completed' },
        { name: 'byUpdatedAt', keyPath: 'updatedAt' }
      ]
    }
  ]
}
});
await client.open();
await client.table('categories').add({
  id: 'work',
  name: 'Work',
  color: '#2563eb',
  createdAt: Date.now(),
  updatedAt: Date.now()
});
await client.table('tasks').add({
  id: 'task-1',
  title: 'Write the Cana tutorial',
  categoryId: 'work',
  completed: false,
  priority: 'high',
  createdAt: Date.now(),
  updatedAt: Date.now()
});
return {
  backend: client.backend,
  category: await client.table('categories').get('work'),
  task: await client.table('tasks').get('task-1')
};

Design notes

Cana is intentionally closer to a small browser database engine than to a frontend state store. IndexedDB owns the durable storage; Cana adds the client surface, explicit transaction outcomes, change replay, crash reconciliation and an optional worker boundary for applications that need to move persistence work off the UI thread.

Mental model in 30 seconds

Read the diagram left to right when the user acts, then right to left when the write commits:

1. Components call a framework action.
2. The action writes to categories or tasks through Cana.
3. IndexedDB commits or rolls back atomically.
4. Cana emits a committed event.
5. Context, Redux or Pinia updates the rendered state from that event.

Postgres-shaped architecture

The analogy is scoped, but useful. PostgreSQL records changes through write-ahead logging , keeps foreground work separate from maintenance work through processes such as the background writer , and lets extensions run background workers . Cana maps those ideas to browser primitives instead of shipping a server:

• Storage layer: IndexedDB is the durable page/store layer and owns atomic commit and rollback. The localStorage fallback is explicit and degraded.
• Commit boundary: a Cana transaction is the unit of durability. Change events are buffered during the body and released only after IndexedDB oncomplete, so subscribers never react to writes that later roll back.
• Logical change stream: subscribers receive committed CanaChangeEvent entries with monotonically increasing cursors. sinceCursor can replay a bounded retained window; if the requested cursor is too old, Cana reports that the UI must resync instead of pretending the replay was complete.
• Crash reconciliation: operationLedger: true writes an operation record in the same transaction as the data. After a killed worker, closed tab, or lost response, resolveWrite() can distinguish committed, rolled-back and unresolvable.
• State-management boundary: Cana does not replace React Context, Redux, Pinia, Zustand or another UI store. The recommended shape is to treat Cana as the durable source of truth, subscribe to Cana events, then update the framework store from those committed events.

Worker model

createWorkerHost() runs a real Cana client behind a MessagePort or dedicated Worker. createRouter() and createWorkerClient() sit on the page side and turn typed method calls into plain messages.

• Messages are structured-cloneable data only: no functions, DOM objects, IDBRequest instances, class instances or Error subclasses cross the boundary.
• Every request carries a requestId, because a worker can answer concurrent requests out of order.
• The default request timeout is 15 seconds. Timed-out reads report Unavailable; timed-out writes report UnknownOutcome, because the worker may have committed before it died or before the response was posted.
• The host broadcasts committed changes as { kind: 'change', event }, which is the hook used by React Context, Redux and Pinia tutorials to refresh their component state.
• Multi-operation transaction() bodies do not cross the worker boundary because the body is a function. Run that transaction inside the worker, or send individual write requests through createWorkerClient().

Performance data

Cana’s browser performance suite runs against real disk-backed IndexedDB. The CI assertions are shape-based instead of clock-based: wall-clock thresholds are too noisy across browsers, disks and shared runners, but recordsExamined, cursorAdvanced and query plans tell us whether the engine is asking the browser to do the right amount of work.

How to read the data

Cana measures two different things:

• Algorithmic shape: what the engine asks IndexedDB to do. The automated suite asserts records examined, cursor advance and index choice instead of guessing performance from a noisy CI clock.
• Local execution time: a browser reference sample. These numbers help you build intuition, but they are not a latency SLA.

Algorithmic model

Measured reference

These numbers are a local reference sample, not a latency SLA. They were measured on 2026-08-13 with Chrome 151 headless, Cypress 15.19.0, Bun 1.3.13 and Node 22.23.1 on macOS 26.5.2, Apple M5, arm64, 24 GB RAM. The benchmark used a fresh IndexedDB database per scenario, the shipped Cana source bundled for the browser, a rows store with primary key id and indexes byGroup / byValue, and validated committed key counts before deleting each database. Read operations show the median of five runs unless noted; bulk writes show one measured run because each run writes a fresh dataset.

What workers change

Workers are most useful for user experience: the UI thread does not own the bulk loop, message validation or change fan-out. For one database and one object store, IndexedDB still serializes the write transaction, so a worker is not a promise of lower total commit time. In the measured run, 10,000 direct writes took 1,811.8 ms and the same 10,000 writes through one dedicated worker took 1,815.4 ms. The worker path is almost the same wall-clock cost, but it keeps the page thread cleaner.

Parallel workers help only when the data can be sharded safely. Four dedicated workers writing four independent 2,500-row databases completed 10,000 total rows in 1,442.6 ms in the local sample. If those workers target the same object store, expect the browser’s storage lock to serialize much of the work.

CI guardrails

The automated performance tests keep these contracts green:

• A limit: 10 query examines 10 records over both 1,000 and 10,000 rows.
• An indexed lookup opens byGroup, avoids full scan and examines only the 100 matching rows in the 10,000-row dataset.
• Deep pagination at offset: 9000, limit: 20 examines 20 records and reports cursorAdvanced: true.
• A full read is the control case: it examines every record, proving the metric can report large work when the query actually asks for it.
• count() agrees with the table size without going through the query path.
• bulkAdd() commits all 10,000 rows in one transaction and reports exactly 10,000 keys.

Junior checklist (“I can …”)

• Open a client, add a row, and read it back.
• Check storage diagnostics after open() when the app needs durability signals.
• Avoid TransactionInactive by keeping foreign awaits outside transactions.

Framework tutorials

Build the same categorized task app with framework state management:

• React Context API
• React Redux
• Vue 3 and Pinia

Use the small integration packages in applications:

bun add @jumentix/cana @jumentix/cana-react
bun add @jumentix/cana @jumentix/cana-vue

Next step

Continue with the consumer usage guide for the full API, querying, transactions, hooks, crash recovery, and troubleshooting. Use designer-core when a Jumentix UI also needs to validate domain documents before persisting them.
